Description
The SSD-AL is an aluminium Ex d Flameproof enclosure designed to house and provide maximum protection for electrical and electronic apparatus within Zone 1 and 21 hazardous areas.
Its flameproof design allows potential sparking equipment to be safely installed in areas where explosive gasses or dust may be present.
The use of 316L marine grade stainless steel provides maximum environmental protection for harsh operating conditions.
Features:
- Apparatus Type: Flameproof Enclosure
- Ingress Protection: IP66 to EN60529
- Material: Enclosure: Marine Grade Aluminium (EN AB 43100) Cover: Marine Grade Aluminium (EN AW 6082) Hinges & Fasteners: 316 Stainless Steel
- Mounting Plate: Galvanized Steel
- Components: Switches, Breakers, RCD units, Indicator lamps, motor controllers, etc.
- Voltage Rating: Up to 24kV ac or 1500V dc
- Cable Entry Variable Metric or NPT entry combinations on any of the 4 sides
- Mounting Via adjustable rear mounting feet (see dimensional data overleaf)
- Area Classification Group IIB Category 2 GD (Zone 1/21 and 2/22), Option: Group IIB+ H2 Category 2 GD (Zone 1/21 and 2/22)
- Type of Protection: Ex db (Flameproof), Ex tb (Dust), Ex db [ia/ib] (Intrinsically Safe)*
- Apparatus Coding: Ex db IIB or IIB+H2 T* Gb, Ex tb* IIIC T* °C Db, Ex db [ia Ga] IIB or IIB+H2 T6 Gb, Ex tb [ia Da] IIIC T85 °C Db, Ex db [ib Gb] IIB or IIB+H2 T6 Gb, Ex tb [ib Db] IIIC T85 °C Db
- Ambient Temperature: -20°C ≤ Tamb ≤ 40°C (with options for +45°C, +50°C, +55°C and +60°C)
- Certificate Number: INERIS 13ATEX0019X / IECEx INE14.0061X
Specifications
| Brand | Abtech |
|---|---|
| Weight | 192 lbs |
| Dimensions | 13.1 × 28.3 × 9.5 in |
| Item Type | Aluminum Enclosure |
| Material | Aluminum |
