Description
The Nimo is an LED submersible luminaire designed for operation in Zone 1 hazardous areas that are prone to flooding or infrequent submersion. It is rated IP68 and both ATEX and IECEx compliant.
This submersible luminaire is manufactured from marine grade 316 (1.404) stainless steel, with toughened borosilicate glass and 316 stainless steel fixings. It has been tested to depths of thirty meters for extended periods. The Nimo's rugged construction ensures that the effects of prolonged exposure to water and marine environments are minimized.
- LED light source for low maintenance operation
- 316 Stainless steel construction for maximum marine protection
- Submersible to a depth of thirty meters for extended periods
- Luminaire Type: Zone 1 Submersible LED Luminaire
- Ingress Protection: IP68 to 30m in accordance with EN60529
- Material: 316 Stainless Steel with toughened glass diffuser and stainless steel fasteners
- Distribution/output: ˜2000 lm
- Lamp Types: Pure white LED 5700K
- LED Life: 50,000 hours L70/B10 @ 25°C
- Cable Entry: 1 x M20 threaded entry
- Terminals: Terminal block for up to 6mm²
- Control Gear: Electronic driver: EN60601-1 (CE), EN61204-3 (EMC), EN61000-4-5 (Surge Protection Class 3)
- Supply: 110 to 250V 50/60Hz ac dc
- Area Classification: Zone 1 Gas and Dust
- Supply: 90 to 250V 50/60Hz AC DC
- Battery: 6V 4.5Ah Ni-Cd
- Emergency Operation: Maintained mode as standard
- Emergency Duration: 180 minutes (3 hours) at 25% output
- Area Classification: Zone 1 & 21, Gas & Dust
- Type of Protection: Ex eb ib qb op is (increased safety, intrinsic safety, quartz filled, optical radiation)
- Apparatus Coding: II 2 GD Ex eb ib qb op is IIB T4
- Certificate Number CML 16ATEX3345, IECEx CML 16.0120
Features:
Specifications:
Specifications
| Brand | Abtech |
|---|---|
| Weight | 19.6 lbs |
| Item Type | Linear LED |
| Power | 12 W |
| Rating | T4 |
