Description
The APC Photocell provides the ability to control the switching of lighting in hazardous areas, without the need for major rewiring of existing circuits.
With an increased focus on reducing carbon footprint combined with a drive to reduce overall operating costs, the APC photocell provides site owners and operators with a method to switch off lighting automatically when a specific light level is reached.
Based on Abtech’s proven BPG enclosure range, the photocell combines tried and tested circuitry with superior ingress and UV protection. The standard switching level is on/off at 70 lux, however, a number of alternate options are available to suit different environmental and site conditions.
The photocell has been designed to avoid ‘nuisance switching’ that can be caused by birds or animals crossing the path of the sensor or extreme overcast conditions. This is achieved with a built-in delay of 25 seconds from the photocell being activated to the switching of mains power to the luminaires.
Features:
-
-
- Reduce carbon emissions and running costs by switching off lighting automatically when a specific light level is reached
- Standard switching level is 70 lux
- Built in delay of 25 seconds to prevent nuisance switching
-
Specifications:
-
- Luminaire Type: Zone 1 photocell
- Ingress Protection: IP66/67 to EN60529
- Material: Glass reinforced polyester housing, polycarbonate sensor window, stainless steel fixings
- Lamp Types: Suitable for use with all lamp types, resistive and inductive loads
- Cable Entry: 4 x M20 tapped entries. Supplied with 4 x Ex plugs
- Terminals: Terminals block for up to 6mm² conductors
- Control Gear: Electronic with on load switching up to 10A
- Orientation: Universal
- Mounting: Via rear mounting holes
- Supply: 110 to 254V 50/60Hz
- Area Classification: Zone 1 & 21, Gas and Dust
- Type of Protection: Ex e mb (increased safety, encapsulation)
- Apparatus Coding: II 2 GD Ex e mb IIC T6 Gb, Ex tb IIIC T80°C Db
- Certificate Number: SIRA 10ATEX5274X / IECEx SIR 10.0171X
Specifications
| Brand | Abtech |
|---|---|
| Weight | 4.4 lbs |
| Item Type | Photocell |
| Current | 10 Amp |
| Light Level | 70 |
| Rating | T6 |
